Product Name: Airbass 2nd (equipped with smart charging box, supports wireless charging and in-ear detection)
Use: for listening to music, watching videos, making calls, and online voice communication
Other functions: Bluetooth renaming, wireless charging, in-ear detection and player control, touch command operation, main and sub-headphone switching
Appearance material: ABS+PC
Bluetooth solution: 6973D4 or 6983D4
Bluetooth version: Bluetooth V5.3
Headphone control method: touch
In-ear detection: support (can be turned off in Bluetooth settings)
Charging box control method: physical button
Wireless charging: support
Bluetooth effective distance: about 20 meters
Hall element function: open the charging box position to start the headset
Connection method: through mobile phone settings - Bluetooth - select the corresponding Bluetooth name to connect
Main parameters
Headphone amplifier type: built-in chip
Speaker unit: Φ13.3 copper ring speaker, impedance 32 ohms
Microphone: sensitivity is - 42dB ±3DB
Built-in earphone battery: 25MAH, No. 2 cobalt 400909
Built-in charging box battery: 200MAH, with lithium battery protection
Music playback time: about 4 hours (at 80% volume)
Talk time: about 4 hours (at 80% volume)
Earphone standby time: about 30 hours
Charging box standby time: about 80 days
Charging input standard: 4.8 - 5.2V
Wired charging current: 230MA
Wireless charging current: 300MA
Wireless charging time: about 100 minutes
Wired charging time: about 70 minutes
Headphone usage instructions
Bluetooth rename: customize the name in the phone settings
Headphone button operation: touch operation
In-ear detection function: automatically pause playback when removing the earphones, automatically play when wearing them
Wired charging: supported
Wireless charging: the charging box indicator light faces up and is placed in the center of the wireless charging station
Power on: automatically turn on when the charging box is opened, and the left and right ears are automatically paired
Power off: automatically turn off when the charging box is placed, and the charging box intelligently detects whether the earphones need to be charged
Connection method: phone settings - Bluetooth - Corresponding Bluetooth name
Manual pairing and clearing: Turn off the Bluetooth of the connected mobile phone, put the earphones into the charging box, press and hold the charging box button for 10 seconds, the indicator light changes from white breathing light to green and then turns off, close the charging box to complete the pairing; if it fails, you can repeat the operation multiple times
Auto-connection after power on: Automatically pair and connect with the connected mobile phone after power on
Reconnect after disconnection: After disconnecting from the mobile phone, it will automatically reconnect within 10 meters within 3 minutes; it will automatically shut down after 3 minutes
Switch between binaural and monaural: When using binaural, take out any earphone and put it into the charging box, and it will automatically switch to monaural; when using monaural, take out the other earphone at any time, and it will automatically switch to binaural
Voice assistant (SIRI): After connecting to the mobile phone, Touch twice on an Apple phone to activate SIRI, and long press on an Android phone to activate the voice assistant
Call operation: Touch once to answer an incoming call; touch once to hang up when a call ends; touch twice to reject an incoming call
Music playback operation: Touch any earphone once to pause/play; touch three times on the left earphone to play the previous song, and touch three times on the right earphone to play the next song
Battery level display: The battery level is displayed on the phone; a reminder tone is emitted every 60 seconds when the earphone is low on battery; the indicator light on the charging box turns orange when the battery level is less than 30%
Charging indicator: When connected to wired charging, the orange indicator light on the charging box lights up for about 5 seconds and automatically turns off when fully charged; when charging wirelessly, place the light hole facing up in the center of the wireless charger, and the indicator light turns on for 3-5 seconds before turning off when charging starts
